Instructions for Fox QS3 shocks for Skinny suspensions

  • Sale
  • Regular price $0.00


Fox Evol/ QS3 shock set up for Skinny suspension







  1. Float/evol front track shock, with no weight on vehicle, either on its side or back end up in the air.
  2. Let the air out of main chamber on front shock, then pump small evol chamber to 160 psi.

Start at 75psi for the main chamber. Adjust for ride preference.

  1. Float/Evol QS3 rear track shock, with no weight on vehicle, either on its side or back end up in the air.
  2. Let the air out of main chamber, then pump Evol chamber to 300 psi, then pump main to 120lbs for a 190 lbs rider. Go up 5 psi for every 20 lbs of rider weight. This is an average, when adjusting main air pressure go 5 lbs at a time to get the desired ride in.
  3. QS3 compression adjuster, number 1 is lightest and rides best, 2 is firmer and for better bottom out resistance, 3 is for aggressive riding or jumping. Always jump or do drops at number 1 on the coupler.
